| Instrument type | Picture | Measuring range Accuracy | Process fitting | Process tempe rature | Process pressure |
| VEGAPULS WL 61 Liquids, in the water and sewage management |  | up to 15 m, +/- 2 mm | Thread G1½, mounting strap, compression flanges from DN 80, 3" | -40 … +80 °C | -1 … +2 bar (-100 … +200 kPa) |
VEGAPULS 61 Liquids under easy process conditions |  | up to 35 m, +/- 2 mm | Thread G1½ 1½NPT, mounting strap, compression flanges from DN 80, 3" | -40 … +80 °C | -1 … +3 bar (-100 … +300 kPa) |
| VEGAPULS 62 Storage tanks,reactors and process vessels, also with arduous process conditions |  | up to 35 m, +/- 2 mm | Thread from G1½ 1½NPT, flanges from DN 50, 2" | -196 … +450 °C | -1 … +160 bar (-100 … +16000 kPa) |
| VEGAPULS 63 Aggressive liquids or with hygienic requirements |  | up to 35 m, +/- 2 mm | Hygienic fittings, boltings, flanges from DN 50, 2" | -196 … +200 °C | -1 … +16 bar (-100 … +1600 kPa) |
| VEGAPULS 65 Liquids under easy process conditions |  | up to 35 m, +/- 8 mm | Thread from G1½ 1½NPT, flanges from DN 50, 2" | -40 … +150 °C | -1 … +16 bar (-100 … +1600 kPa) |
| VEGAPULS 66 Storage tanks,process vessels or standpipes under arduous process conditions |  | up to 35 m, +/- 8 mm | Flanges from DN 50, 2" | -60 … +400 °C | -1 … +160 bar (-100 … +16000 kPa) |
